MaxiCheck MX808S-TS

Together with the ability to quickly read and clear DTCs for all available modules of the majority of the makes and models on the market, MaxiCheck MX808S-TS provides superior special functions, including Oil Reset, EPB (Electronic Parking Brake), SAS (Steering Angle Sensor), and BMS (Battery Management System). In addition to OBDII diagnostics and special functions, MX808S-TS can perform comprehensive TPMS services with ease.

  • image 0

• Read and erase codes for all available systems


• View and graph Live Data


• Perform bi-directional Active Tests


• AutoVIN technology automatically identifies vehicle make, model, and year


• Advanced TPMS diagnostics for complete TPMS service


• Activate all known TPMS sensors


• Program AUTEL MX-Sensors to replace 99% of the TPMS on vehicles on the road today


• Comprehensive OBDII Relearn coverage


• Displays vehicle-specific Relearn instructions


• 7-inch LCD capacitive touchscreen with 1024 x 600 resolution display


• Powerful Cortex-A55 processor (1.8 GHz) processor


• 64GB on-board memory for better performance


• Android 11 operating system for fast boot-up and multitasking


• Reset Steering Angle Sensor (SAS)


• Reset service mileage and service intervals


• Reset Electronic Parking Brake


• Perform DPF regeneration


• Reset Injectors


• Support battery registration and reset


• Compatible with Videoscope


Operating   SystemAndroid 11
ProcessorCortex-A55 quad-core processor (1.8GHz)
Memory4GB RAM & 64GB On-board Memory
Display7-inch LCD capacitive touchscreen with 1024x600 resolution
ConnectivityWi-Fi（802.11a/b/g/n/ac）
USB 2.0，Mini USB 2.0
Wireless BT V2.1+EDR
HDMI Type A
SD Card (Support up to 64GB)
SensorsLight sensor for brightness auto adjust
Audio Input/OutputInput: N/A
Output: Beep
Power and Battery3.7 V/5000mAh lithium-polymer battery
Charges via 5 VDC power supply
Input Voltage5 V/1.5 A
Operating Temp0 to 50°C (32 to 122°F)
Storage Temp -10 to 60°C (14 to 140°F)
Dimensions(WXHX D)270.8 mm (10.0”) x 176.0 mm(6.9”) x 36.0 mm (1.4”)
Weight885 g (2.31 lb.)
Protocols
 ISO9141-2, ISO14230-2, ISO15765, K/L-Line, Flashing   Code, SAE-J1850 VPW, SAE-J1850PWM,   ISo11898(Highspeed, Middlespeed, Lowspeed    and Singlewire CAN, fault-tolerant CAN) SAE J2610, GM UART UART Echo   Byte Protocol, Honda Diag-H Protocol,TP2.0,TP1.6



MaxiCheck MX808S-TSMaxiCheck MX808S
Read Codes√√
Erase Codes√√
Live Data√√
ECU Information√√
Active Test√√
Service Functions√√
Complete OBD Diagnositcs√√
Oil Serive Reset√√
Parking Brake Pad Relearn After   Replacement√√
Steering Angle Sensor Relearn√√
Battery Registration and Reset√√
Diesel Particulate Filter Regeneration√√
Tire Pressure Monitoring SystemCompleteBasic
Immobilizer FunctionBasicBasic
Advanced TPMS Diagnostics for Complete   TPMS Health Check√--
Activate 98% of All Known TPMS Sensors√--
Program AUTEL MX-Sensors√--
Comprehensive OBD relearn coverage√--
On-screen Relearn Procedure√--
Battery Analysis√--
Videoscope√√
ProcessorQuad-core 1.8GHzQuad-core 1.8GHz
Operating SystemAndroid 11Android 11
Memory4G + 64G4G + 64G
Display7" LCD7" LCD
Battery5000 mAh5000 mAh
Internet UpdatableWiFiWiFi
Multilingual Support√√
Historical Test Records√√
Save and Playback Data√√
Print Data via Windows PC √√
Vehicle communication methodWireless (bluetooth)Wired


  • Description

    • • Read and erase codes for all available systems


    • View and graph Live Data


    • Perform bi-directional Active Tests


    • AutoVIN technology automatically identifies vehicle make, model, and year


    • Advanced TPMS diagnostics for complete TPMS service


    • Activate all known TPMS sensors


    • Program AUTEL MX-Sensors to replace 99% of the TPMS on vehicles on the road today


    • Comprehensive OBDII Relearn coverage


    • Displays vehicle-specific Relearn instructions


    • 7-inch LCD capacitive touchscreen with 1024 x 600 resolution display


    • Powerful Cortex-A55 processor (1.8 GHz) processor


    • 64GB on-board memory for better performance


    • Android 11 operating system for fast boot-up and multitasking


    • Reset Steering Angle Sensor (SAS)


    • Reset service mileage and service intervals


    • Reset Electronic Parking Brake


    • Perform DPF regeneration


    • Reset Injectors


    • Support battery registration and reset


    • Compatible with Videoscope


  • Specifications
    • Operating   SystemAndroid 11
    ProcessorCortex-A55 quad-core processor (1.8GHz)
    Memory4GB RAM & 64GB On-board Memory
    Display7-inch LCD capacitive touchscreen with 1024x600 resolution
    ConnectivityWi-Fi（802.11a/b/g/n/ac）
    USB 2.0，Mini USB 2.0
    Wireless BT V2.1+EDR
    HDMI Type A
    SD Card (Support up to 64GB)
    SensorsLight sensor for brightness auto adjust
    Audio Input/OutputInput: N/A
    Output: Beep
    Power and Battery3.7 V/5000mAh lithium-polymer battery
    Charges via 5 VDC power supply
    Input Voltage5 V/1.5 A
    Operating Temp0 to 50°C (32 to 122°F)
    Storage Temp -10 to 60°C (14 to 140°F)
    Dimensions(WXHX D)270.8 mm (10.0”) x 176.0 mm(6.9”) x 36.0 mm (1.4”)
    Weight885 g (2.31 lb.)
    Protocols
     ISO9141-2, ISO14230-2, ISO15765, K/L-Line, Flashing   Code, SAE-J1850 VPW, SAE-J1850PWM,   ISo11898(Highspeed, Middlespeed, Lowspeed    and Singlewire CAN, fault-tolerant CAN) SAE J2610, GM UART UART Echo   Byte Protocol, Honda Diag-H Protocol,TP2.0,TP1.6


  • Video
  • Comparison

    		• MaxiCheck MX808S-TSMaxiCheck MX808S
    Read Codes√√
    Erase Codes√√
    Live Data√√
    ECU Information√√
    Active Test√√
    Service Functions√√
    Complete OBD Diagnositcs√√
    Oil Serive Reset√√
    Parking Brake Pad Relearn After   Replacement√√
    Steering Angle Sensor Relearn√√
    Battery Registration and Reset√√
    Diesel Particulate Filter Regeneration√√
    Tire Pressure Monitoring SystemCompleteBasic
    Immobilizer FunctionBasicBasic
    Advanced TPMS Diagnostics for Complete   TPMS Health Check√--
    Activate 98% of All Known TPMS Sensors√--
    Program AUTEL MX-Sensors√--
    Comprehensive OBD relearn coverage√--
    On-screen Relearn Procedure√--
    Battery Analysis√--
    Videoscope√√
    ProcessorQuad-core 1.8GHzQuad-core 1.8GHz
    Operating SystemAndroid 11Android 11
    Memory4G + 64G4G + 64G
    Display7" LCD7" LCD
    Battery5000 mAh5000 mAh
    Internet UpdatableWiFiWiFi
    Multilingual Support√√
    Historical Test Records√√
    Save and Playback Data√√
    Print Data via Windows PC √√
    Vehicle communication methodWireless (bluetooth)Wired
