MaxiCOM MK900-BT

All Systems Diagnostics and Service Tablet

Featuring the powerful quad-core processor, and an 8.0-inch LCD capacitive touchscreen, based on the Android multitasking operating system, and combined with the ability to quickly read and clear DTCs for all available modules of the majority of the makes and models on the market, the MaxiCOM MK900-BT is your ideal auto diagnostics and service tool, providing you with superior functions, including Oil Reset, EPB (Electronic Parking Brake), SAS (Steering Angle Sensor), BMS (Battery Management System), and DPF (Diesel Particulate Filter).

  • image 1

· MaxiVCI V150 for wireless connection
· 8-inch high-resolution, responsive touchscreen display
· Android 11 operating system offers advanced streamlined functionality
· Extensive vehicle coverage for U.S., Asian, and European vehicle makes
· Exceptional OE-Level system coverage for all electronic systems
· Complete code, live data, ECU information, active test, and special function capabilities
· Supports the latest communication protocols, including DoIP and CAN FD
· Smart AutoVIN technology for quick and accurate vehicle identification
· Expansive menu of service and maintenance tasks
· Detailed Pre- and Post Scan Reporting
· Automatic system and software updates with real-time Wi-Fi push notifications
· Remote Access Technical Support Troubleshooting
· One-stop multitasking designed for ideal management of workshop operations to keep all data files, customer info, and vehicle records well organized
· Convenient data management system for managing internal applications and reviewing data

Operating SystemAndroid 11
ProcessorQuad core Processor(1.8GHz)
Memory4GB RAM & 64GB ROM
Display8-inch LCD capacitive touchscreen with 1280x800 resolution
Rear Camera8 MP
ConnectivityUSB Type-C
USB 2.0
Wi-Fi
Bluetooth
Mini SD card (supports up to 64GB)
Audio Input/OutputInput: N/A
Output: buzzer
Power and Battery3.7 V/7700mAh lithium-polymer battery
Charges via 5 VDC power supply
Battery Charging Input5 V/3 A
Operating Temp0 to 50°C (32 to 122°F)
Storage Temp-10 to 60°C (14 to 140°F)
Protocols
ISO9141-2, ISO14230-2, ISO15765, K/L-Line, Flashing   Code, SAE-J1850 VPW, SAE-J1850PWM, ISO11898(High-speed, Middle-speed, Low-speed  and Single-wire CAN, fault-tolerant CAN) , SAE J2610, GM UART, UART Echo Byte Protocol, Honda Diag-H Protocol, TP2.0, TP1.6, DoIP, CANFD



MaxiCOM MK900-BTMaxiCOM MK900MaxiCOM MK900-TSMaxiCOM MK808-BT
Read Codes
Erase Codes
Live Data
ECU Information
Active Test
Service Functions√ √
Complete OBD Diagnositcs
Pre & Post Scan--
Scan VIN--
Tire Pressure Monitoring SystemBasicBasicCompleteBasic
Immobilizer FunctionBasicBasicBasicBasic
Advanced TPMS Diagnostics for Complete TPMS Health Check------
Activate All Known TPMS Sensors------
Program AUTEL MX-Sensors------
Comprehensive OBD relearn coverage------
On-screen Relearn Procedure------
DoIP--
CANFD√(optional adapter)
Battery Analysis--
Videoscope
ProcessorQuad-core 1.8GHzQuad-core 1.8GHzQuad-core 1.8GHzQuad-core 1.6GHz
Operating SystemAndroid 11Android 11Android 11Android 4.4.4
Memory4G + 64G4G + 64G4G + 64G1G + 64G
Display8" LCD8" LCD8" LCD7" LCD
Battery7700mAh7700mAh7700mAh5000mAh
Internet UpdatableWi-FiWi-FiWi-FiWi-Fi
Multilingual Support
Historical Test Records
Save and Playback Data
Wi-Fi Print --
Vehicle communication methodWireless (bluetooth)WiredWireless (bluetooth)Wireless (bluetooth)
