MaxiCOM MK900-TS

AUTOMOTIVE DIAGNOSIS SYSTEM

Together with the ability to quickly read and clear DTCs for all available modules of the majority of the makes and models on the market, MaxiCOM MK900-TS provides superior special functions, including Oil Reset, EPB (Electronic Parking Brake), SAS (Steering Angle Sensor), and BMS (Battery Management System). In addition to OBDII diagnostics and special functions, MK900-TS can perform comprehensive TPMS services with ease.

  • image 1

· Extensive vehicle coverage for U.S., Asian, and European vehicle makes
· Exceptional OE-Level system for all electronic systems
· Excellent functions for reading codes, live data, ECU information and performing active test, adapation, and matching, etc.
· Features DoIP and CAN FD protocols
· Smart AutoVIN technology for identifying vehicles easily
· Automatic system and software updates with real-time push notifications through the Internet
· Instant remote control tech support anytime and anywhere
· Advanced TPMS diagnostics with DTC description
· TPMS status, one step for complete TPMS health check
· Activate all known TPMS sensors
· Program AUTEL MX-Sensor
· Comprehensive OBD relearn coverage
· On-screen relearn procedure
· One-stop multitasking designed for ideal management of workshop operations to keep all data files, customer info, and vehicle records well organized
· Supports Pre & Post Scan

Operating SystemAndroid 11
ProcessorQuad core Processor(1.8GHz)
Memory4GB RAM & 64GB ROM
Display8-inch LCD capacitive touchscreen with 1280x800 resolution
Rear Camera8 MP
ConnectivityUSB Type-C
USB 2.0
Wi-Fi
Bluetooth
Mini SD card (supports up to 64GB)
Audio Input/OutputInput: N/A
Output: buzzer
Power and Battery3.7 V/7700mAh lithium-polymer battery
Charges via 5 VDC power supply
Battery Charging Input5 V/3 A
Operating Temp0 to 50°C (32 to 122°F)
Storage Temp-10 to 60°C (14 to 140°F)
Protocols
ISO9141-2, ISO14230-2, ISO15765, K/L-Line, Flashing   Code, SAE-J1850 VPW, SAE-J1850PWM, ISO11898(High-speed, Middle-speed, Low-speed  and Single-wire CAN, fault-tolerant CAN) , SAE J2610, GM UART, UART Echo Byte Protocol, Honda Diag-H Protocol, TP2.0, TP1.6, DoIP, CANFD



MaxiCOM MK900-TSMaxiCOM MK900-BTMaxiCOM MK900MaxiCOM MK808TS
Read Codes√√√√
Erase Codes√√√√
Live Data√√√√
ECU Information√√√√
Active Test√√√√
Service Functions√(40+kinds)√(40+kinds)√(40+kinds)√(36 kinds)
Complete OBD Diagnositcs√√√√
Pre & Post Scan√√√--
Scan VIN√√√--
Tire Pressure Monitoring SystemCompleteBasicBasicComplete
Immobilizer FunctionBasicBasicBasicBasic
Advanced TPMS Diagnostics for Complete TPMS Health Check√----√
Activate All Known TPMS Sensors√----√
Program AUTEL MX-Sensors√----√
Comprehensive OBD relearn coverage√----√
On-screen Relearn Procedure√----√
DoIP√√√--
CANFD√√√√（optional adapter）
Battery Analysis√√--√
Videoscope√√√√
ProcessorQuad-core 1.8GHzQuad-core 1.8GHzQuad-core 1.8GHzQuad-core 1.6GHz
Operating SystemAndroid 11Android 11Android 11Android 4.4.4
Memory4G + 64G4G + 64G4G + 64G1G + 64G
Display8" LCD8" LCD8" LCD7" LCD
Battery7700mAh7700mAh7700mAh5000mAh
Internet UpdatableWiFiWi-FiWiFiWiFi
Multilingual Support√√√√
Historical Test Records√√√√
Save and Playback Data√√√√
Print Data via Windows PC √√√√
Vehicle communication methodWireless (bluetooth)Wireless (bluetooth)WiredWireless (bluetooth)


  • Description

    • · Extensive vehicle coverage for U.S., Asian, and European vehicle makes
    · Exceptional OE-Level system for all electronic systems
    · Excellent functions for reading codes, live data, ECU information and performing active test, adapation, and matching, etc.
    · Features DoIP and CAN FD protocols
    · Smart AutoVIN technology for identifying vehicles easily
    · Automatic system and software updates with real-time push notifications through the Internet
    · Instant remote control tech support anytime and anywhere
    · Advanced TPMS diagnostics with DTC description
    · TPMS status, one step for complete TPMS health check
    · Activate all known TPMS sensors
    · Program AUTEL MX-Sensor
    · Comprehensive OBD relearn coverage
    · On-screen relearn procedure
    · One-stop multitasking designed for ideal management of workshop operations to keep all data files, customer info, and vehicle records well organized
    · Supports Pre & Post Scan

  • Specifications
    • Operating SystemAndroid 11
    ProcessorQuad core Processor(1.8GHz)
    Memory4GB RAM & 64GB ROM
    Display8-inch LCD capacitive touchscreen with 1280x800 resolution
    Rear Camera8 MP
    ConnectivityUSB Type-C
    USB 2.0
    Wi-Fi
    Bluetooth
    Mini SD card (supports up to 64GB)
    Audio Input/OutputInput: N/A
    Output: buzzer
    Power and Battery3.7 V/7700mAh lithium-polymer battery
    Charges via 5 VDC power supply
    Battery Charging Input5 V/3 A
    Operating Temp0 to 50°C (32 to 122°F)
    Storage Temp-10 to 60°C (14 to 140°F)
    Protocols
    ISO9141-2, ISO14230-2, ISO15765, K/L-Line, Flashing   Code, SAE-J1850 VPW, SAE-J1850PWM, ISO11898(High-speed, Middle-speed, Low-speed  and Single-wire CAN, fault-tolerant CAN) , SAE J2610, GM UART, UART Echo Byte Protocol, Honda Diag-H Protocol, TP2.0, TP1.6, DoIP, CANFD


  • Video
  • Comparison

    		• MaxiCOM MK900-TSMaxiCOM MK900-BTMaxiCOM MK900MaxiCOM MK808TS
    Read Codes√√√√
    Erase Codes√√√√
    Live Data√√√√
    ECU Information√√√√
    Active Test√√√√
    Service Functions√(40+kinds)√(40+kinds)√(40+kinds)√(36 kinds)
    Complete OBD Diagnositcs√√√√
    Pre & Post Scan√√√--
    Scan VIN√√√--
    Tire Pressure Monitoring SystemCompleteBasicBasicComplete
    Immobilizer FunctionBasicBasicBasicBasic
    Advanced TPMS Diagnostics for Complete TPMS Health Check√----√
    Activate All Known TPMS Sensors√----√
    Program AUTEL MX-Sensors√----√
    Comprehensive OBD relearn coverage√----√
    On-screen Relearn Procedure√----√
    DoIP√√√--
    CANFD√√√√（optional adapter）
    Battery Analysis√√--√
    Videoscope√√√√
    ProcessorQuad-core 1.8GHzQuad-core 1.8GHzQuad-core 1.8GHzQuad-core 1.6GHz
    Operating SystemAndroid 11Android 11Android 11Android 4.4.4
    Memory4G + 64G4G + 64G4G + 64G1G + 64G
    Display8" LCD8" LCD8" LCD7" LCD
    Battery7700mAh7700mAh7700mAh5000mAh
    Internet UpdatableWiFiWi-FiWiFiWiFi
    Multilingual Support√√√√
    Historical Test Records√√√√
    Save and Playback Data√√√√
    Print Data via Windows PC √√√√
    Vehicle communication methodWireless (bluetooth)Wireless (bluetooth)WiredWireless (bluetooth)
